Magnetism

Magnetism

Magnetism is a force that acts at a distance and is caused by a magnetic field. This force strongly attracts ferromagnetic materials such as iron, nickel and cobalt. In magnets, the magnetic force strongly attracts an opposite pole of another magnet and repels a like pole. The magnetic field is both similar and different than an electric field.

Questions you may have include:

  • What is a magnetic field?

  • What is a magnetic force?

  • How do magnetic and electric fields compare?

Magnetic field

A magnetic field consists of imaginary lines of flux coming from moving or spinning electrically charged particles. Examples include the spin of a proton and the motion of electrons through a wire in an electric circuit.

What a magnetic field actually consists of is somewhat of a mystery, but we do know it is a special property of space.

Magnetic field or lines of flux of a moving charged particle

Names of poles

The lines of magnetic flux flow from one end of the object to the other. By convention, we call one end of a magnetic object the N or North-seeking pole and the other the S or South-seeking pole, as related to the Earth's North and South magnetic poles. The magnetic flux is defined as moving from N to S.

Magnets

Although individual particles such as electrons can have magnetic fields, larger objects such as a piece of iron can also have a magnetic field, as a sum of the fields of its particles. If a larger object exhibits a sufficiently great magnetic field, it is called a magnet.

Magnetic force

The magnetic field of an object can create a magnetic force on other objects with magnetic fields. That force is what we call magnetism.

When a magnetic field is applied to a moving electric charge, such as a moving proton or the electrical current in a wire, the force on the charge is called a Lorentz force.

Attraction

When two magnets or magnetic objects are close to each other, there is a force that attracts the poles together.

Force attracts N to S

Magnets also strongly attract ferromagnetic materials such as iron, nickel and cobalt.

Repulsion

When two magnetic objects have like poles facing each other, the magnetic force pushes them apart.

Force pushes magnetic objects apart

Magnets can also weakly repel diamagnetic materials.

Magnetic and electric fields

The magnetic and electric fields are both similar and different. They are also inter-related.

Electric charges and magnetism similar

Just as the positive (+) and negative (-) electrical charges attract each other, the N and S poles of a magnet attract each other.

In electricity like charges repel, and in magnetism like poles repel.

Electric charges and magnetism different

The magnetic field is a dipole field. That means that every magnet must have two poles.

On the other hand, a positive (+) or negative (-) electrical charge can stand alone. Electrical charges are called monopoles, since they can exist without the opposite charge.

In conclusion

Magnetism is a force that acts at a distance and is caused by a magnetic field. The magnetic force strongly attracts an opposite pole of another magnet and repels a like pole. The magnetic field is both similar and different than an electric field.
